Code:Yellow Green
| Parameter |
Symbol |
Condition |
Min |
Typ |
Max |
Unit |
| Forward Voltage |
Vf |
If=20mA |
1.8 |
|
2.5 |
V |
| Reverse Voltage |
Vr |
Ir=10uA |
5 |
|
|
V |
| Luminous Intensty |
Iv |
If=20mA |
20 |
|
40 |
mcd |
| Spectrum With Of Half Value |
λ |
If=20mA |
|
20 |
|
nm |
| Wavelength |
Dλ |
If=20mA |
569 |
|
574 |
nm |
Absolute Maximum Ratings(Ta=25℃)
| Parameter |
Symbol |
Ratings |
Unit |
| Forward Current(per dice) |
Ipm |
20 |
mA |
| Reverse Voltage(per dice) |
Vr |
5 |
V |
| Power Dissipation(per dice) |
Pm |
80 |
mW |
| Operating Temperature Range |
Topr |
-40~+120 |
℃ |
| Storage Temperature Range |
Tstg |
-40~+120 |
℃ |
| Solder Temperature(3 sec) |
Th |
260 |
℃ |
LED working lifetime 80,000hrs, Absolute Maximum Rating at Ta=25℃
Why choose us?
1. Best quality
- Three times of inspection on all products on production:
Step 1；raw material check
Step 2: process check and full inspection after chip&wire bonding
Step 3: full test before packing and partial check before shipment
2. Best price
- manufacturer
- best suppliers sources
- all products by oneself
3. Our customer
- long-term relationships with Gree, Media, Panasonic, Chigo, TCL, Samsung, Kone Elevators, Hisense etc
4. Company strength
- good quality&competitive price
- listed company
- factory of over 100 workers, with many auto-machines under advanced ERP management.
- management system: ISO 9001:2008,SGS
FAQ
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.Our company mainly produces Segment LED Displays.
Q: How long is your delivery time?
A: Delivery time:About 15-20 days; According to order quantity.
Q: What is your terms of payment?
A: T/T,Western Union,Paypal with small amount.
Q: How can I get your catalogue and price list?
A: Please let us know your email or contact us from website directly for our catalogue and price list.
Q: Can I negotiate the prices?
A: Yes, we may consider discounts for multiple container load of mixed goods.
Q: How much will the shipping charges be?
A: It depends on the size of your shipment and the method of shipping.
We will offer the charge to you as you requested.
Q: May I have some samples for testing?
A: Yes,we can provide 5-10pcs free samples in your delivery cost.
